1x12 Combo Specifications
  • Hand Wired All Tube Combo Amplifier
  • 22 Watts Output
  • Two Channels
  • Normal & Bright Inputs (each per channel)
  • Two Volume Controls (individual per channel)
  • Master Tone Control
  • Tube Compliment:
    • 1-12AX7 Preamp Tube
    • 1-12AY7 Preamp Tube
    • 1-5U4 Rectifier
    • 2-Matched 6V6 Output Tubes
  • Celestion Blue Twelve Inch Alnico Speaker
  • Speaker Impedance: 8 ohms
  • Open Back Cabinet Design
  • On/Off Toggle Switch
  • Jeweled Illuminated Power Indicator
  • Standby Toggle Switch
  • Fuse Protection
  • Grounded Plug
  • Stitched Leather Strap Handle
  • Tolex Covering (Red)
  • Finger Jointed Pine Cabinet Construction
  • Optional Fitted Cover Available
  • Weight: 31 lbs.
  • Dimensions: 16" H x 20" W x 9.5" D
